Product Details
Ti 6Al-4V, or Grade 5 titanium, known as the “workhorse” of the titanium alloys, is the most commonly used of all titanium alloys. It accounts for 50 percent of total titanium usage the world over.
Its usability lies in its many benefits. Ti 6Al-4V may be heat treated to increase its strength. It can be used in welded construction at service temperatures of up to 600° F. This alloy offers its high strength at a light weight, useful formability and high corrosion resistance.
Grade 5 Titanium Sheet Chemical Composition | |||||||||||
Grade | N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti |
GR 5 | 0.05 | 0.06 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
Grade 5 Titanium Sheet Physical Properties | ||||||
Grade | State | Tensile Strength(min) | Yield Strength(min) | Elongation (%) | ||
Ksi | MPa | Ksi | MPa | |||
GR 5 | (M)Annealed | 130 | 895 | 120 | 828 | 10 |
Grade 5 Titanium Sheet Product Specifications | |||
Processing | Sizes | ||
Thickness(mm) | Width(mm) | Length(mm) | |
Hot Rolling | >4.75~60.0 | 400~3000 | 1000~10000 |
Cold Rolling | 0.30~6 | 400~2000 | 1000~Max |
Product Application
Grade 5 Titanium Sheet Application:
Aircraft turbines
Engine components
Aircraft structural components
Aerospace fasteners
High-performance automatic parts
Marine applications
Sports equipments
Packing:
1. Packed with wooden case
2. Cardboard case
3. According to the requirements of customers
Shipment type:
1. Sea Freight
2. Air Cargo
3. Express delivery
4. Land Transportation
Our Service
Premium Quality
Fast Delivery
Small Order Acceptable
Wonderful Teamwork
Spot delivery, including delivering small batches of goods
Provide wide-range and complete materials series products
Our application technology expert provide the best material and recommendation
One-stop service
